C Type Conveyor Belt Spot Repair Vulcanizer

Qingdao Running Machine Co.,Ltd
Contact Now

C Type Conveyor Belt Spot Repair Vulcanizer

Brand Name : RUNNING

Model Number : 350*350

Certification : CE

Place of Origin : QINGDAO CHINA

MOQ : 1 set

Price : $2,000 ~ $3,000 / set

Payment Terms : T/T, L/C

Supply Ability : 50 sets/month

Delivery Time : 7 work day

Packaging Details : Plywood case (Fumigation)

Usage : broken conveyor belt repairing

Type : spot type

Heating plate size : 350*350mm or customized

Pressurizing : Manual pump

Frame span : 1100mm

Weight : 160kg

Contact Now

C-type Aluminum Frame Conveyor Belt Spot Repairing Machine

Usage:

This C-type conveyor belt repairing machine is an electric heating repair equipment for conveyor belt. During use, the surface of the belt may be damaged or pierced by the conveying material. Then the spot vulcanizing repair machine can be used to fix it.

The machine consists of frame, two heating plates, an integrated hydraulic lifter and an electric control box. The frame is made of high-strength aluminum alloy, it's small size, portable, safe and reliable. This machine is mainly applied to repair less than 300 * 300 dot damage.

C Type Conveyor Belt Spot Repair Vulcanizer

C Type Conveyor Belt Spot Repair Vulcanizer

Machine specification of conveyor belt repairing machine:

C Type Conveyor Belt Spot Repair Vulcanizer

Steps for usage:

1. Transfer machine to the repair site.
2. Fill glue in the damaged areas that need to be repaired (see the adhesive part in the vulcanization process of the belt joints, or the demonstration by our staff when the equipment is being tested).
3. Place the frame under the belt and align it with the damaged area.
4. Place the down heating plate just below the damaged area of the belt and then place the upper frame.
5. Press the hydraulic lever until it reaches enough pressure level.
6. Get the first power wire well connected to the electrical control box. Connect the second wire with the electric control box and the upper and down plates.
Note that it corresponds to the sign on the electric control box.
7. Turn on the electric control box and start the vulcanizing repair process.

C Type Conveyor Belt Spot Repair Vulcanizer

The conveyor belt repairing machine is made of high-strength aluminum alloy, at the same time it's lightweight, very easy for moving.

C Type Conveyor Belt Spot Repair Vulcanizer

Shipping package of conveyor belt repairing machine:

C Type Conveyor Belt Spot Repair Vulcanizer

There are lots of machines for your choice, please feel free to contact us for more machine details.

C Type Conveyor Belt Spot Repair Vulcanizer
